Cost-effective Nitrogen Analyzer Factory for Hospital

Product Overview

Note: the detailed introduction you provided describes the TPbG-3055 Online Total Lead Analyzer (an optical heavy?metal analyzer). Below is a concise 5?point summary based on that description.

Product Features

1) Product overview

Product Value

- TPbG-3055 is an online automatic total lead analyzer using spectrophotometry (optical method) designed to meet national environmental protection standards.

Product Advantages

- It continuously measures total lead by forming a colored complex (lead + indicator under alkaline conditions) and converting color change to a lead concentration.

Application Scenarios

- Manufactured by Shanghai Boqu Instrument Co., Ltd., marketed for industrial and environmental monitoring and exported to multiple countries.

2) Product features

- Measuring range: 0.00–3.00 mg/L.

- Accuracy: ≤±10% (when ≥0.2 mg/L); ≤±0.02 mg/L (when

- Adjustable digestion time: 5–120 minutes; minimum measurement period ~50 minutes (adjustable to sample).

- Sampling modes: time interval (55–9999 min adjustable) and integral time measurement; calibration period adjustable (1–99 days).

- Outputs and interfaces: two 4–20 mA channels, RS232, RS485.

- Operation: touch screen with command input; automatic discharge of residual reagents after reset/power cycle; data retained on alarms and power loss.

- Environmental/power: recommended +5–28 °C, humidity ≤90% (no condensation); AC 220 V ±10%, 50 Hz, 5 A. Size H1450 × W510 × L450 mm.

3) Product value

- Enables continuous, automated online monitoring of total lead, reducing the need for frequent manual laboratory tests.

- Supports regulatory compliance and early detection of heavy?metal exceedances in water streams.

- Provides reliable, saved data and remote outputs for integration into plant control or environmental reporting systems.

- Cost?effective for sustained monitoring programs due to automation, adjustable schedules, and low maintenance frequency.

4) Product advantages

- Good analytical performance: reasonably wide measuring range with specified accuracy, repeatability, and stability.

- Flexible and configurable: adjustable digestion time, sampling interval, and calibration periods to suit different water matrices and monitoring needs.

- Automated reagent management and residual discharge reduce manual intervention and startup issues.

- Standard industrial interfaces (4–20 mA, RS232/485) make system integration straightforward.

- Compact footprint and monthly maintenance requirement (≈30 minutes) support practical field use.

5) Application scenarios

- Continuous monitoring of surface water, rivers and lakes for lead contamination.

- Industrial process water and industrial wastewater monitoring (metallurgy, plating, electronics, chemical plants).

- Environmental protection and heavy?metal prevention/control projects required by regulation.

- Municipal and hospital wastewater monitoring (real?time detection of lead in effluent streams and compliance checks).

- Integration into treatment plant process control and remote environmental monitoring networks.
